** MADE IN USA **

V3 UPDATES:

Made in America
Complete motor/spider/voice coil redesign
Added 0.5" wind height to voice coil

Wolfram Audio introduces the Au-15: our unrivaled 15" SPL woofer when it comes to power, performance, and reliability. The Au series features a massive 300oz magnet coupled with a heavily vented magnetic gap for extreme cooling. The Au-15 utilizes a 3" 4-layer high temperature voice coil for an intense amount of power handling.

Au is the chemical symbol for Gold - one of the most rare and valuable metals of the face of the earth. That is exactly why the Au series from Wolfram Audio is the top choice for SPL woofers in it's class.

Specifications:

Wolfram Audio Au-15 V3 - 15" SPL Subwoofer
Dual 1 or 2 Ohm Voice Coil Configuration
Peak Power : 5000 Watts
RMS Power : 2500 Watts
Competition Grade Pressed Paper Cone
High Roll Foam Surround
Massive Triple Stacked Magnet
4 layer Nomex Spider
3" Flatwound Alumimum PE Voice Coil
4 Gauge Push Terminals

Sensitivity : 89.8 dB
Fs : 29.23 Hz
Re : 3.42 Ohm
Qms : 5.19
Qes : 0.46
Qts : 0.42
Cms : 84.63 uM/N
Bl : 21.82
Vas : 75.36 L
Mms : 350.35 g
Xmax : 38 mm (One-Way)

Enclosure Recommendations:

2.5 - 2.75 ft³ Sealed
3.5 - 4.0 ft³ Ported (Tuned 32hz - 34hz)
Mounting Depth: 9 7/8"
Cutout Diameter: 14 1/8""
Displacement: 0.17 ft³
