Hg-10 V2 | 10" SPL Subwoofer

ALL NEW HG-v2 : New motor and soft part design along with the all time favored PE Coil

Wolfram Audio introduces the new revision of our Hg-10: our unrivaled 10" SPL woofer when it comes to power, performance, and reliability. The Hg series features a massive 300oz magnet coupled with a heavily vented magnetic gap for extreme cooling. The Hg-10 utilizes a 3" 4-layer high temperature voice coil for an intense amount of power handling.

Specifications:

• Wolfram Audio Hg-10  - 10" SPL Subwoofer
• Dual 1 or 2 Ohm Voice Coil Configuration
• Peak Power : 4000 Watts
• RMS Power : 2000 Watts
• Competition Grade Pressed Paper Cone
• Stitched High Roll Foam Surround
• Massive Triple Stacked Magnet
• 4 layer Nomex spider
• 3" Flat AL Wire Voice Coil
• 4 Gauge Push Terminals

• Sensitivity : 84.2 dB
• Fs : 39.4 Hz
• Re :  1 or 2 Ohm
• Qms : 2.25
• Qes :  0.39
• Qts :  0.33
• Nref :  0.165%
• Cms :  0.07 mm/N
• Bl :  15.6
• Vas :  10.9 L
• Mms :  229.3 gr
• Xmax :  10mm (One-Way)

Enclosure Recommendations:

• .75 - 1.00 ft³ Sealed
• 1.5 - 2.0 ft³ Ported (Tuned 32hz - 34hz)
• Mounting Depth: 8"

• Cutout Diameter: 10.07"
• Displacement: 0.15 ft³
